AIYOS
Triple-Screen Synergy: Triple Your Ad Revenue & ROIFeaturing three independent display panels, this kiosk allows operators to maximize advertising revenue by streaming high-definition video ads, interactive wayfinding maps, and real-time news or promotions simultaneously. Drive unprecedented user engagement and triple your commercial monetization potential in a single footprint.
Full Optical Lamination: Zero Fogging & Crystal-Clear Outdoor DisplayEngineered with advanced full optical bonding, the gap between the LCD panel and AR tempered glass is completely eliminated. This prevents internal moisture condensation, screen fogging, and dust accumulation during severe temperature drops, delivering brilliant color contrast and clear readability under direct sunlight.
Ultra-Narrow Bezel Architecture: Seamless Panoramic AestheticsDesigned with an exceptionally thin frame, the narrow-bezel structure provides an ultra-modern, high-end visual appearance. The minimalist profile seamlessly integrates into luxury shopping centers, modern transit hubs, and smart city infrastructure, enhancing the surrounding architecture while commanding passerby attention.
2500–4500 Nits Ultra-High Brightness with Intelligent Auto-DimmingEquipped with commercial-grade high-brightness panels and anti-reflective (AR) glass, the display remains fully legible even under intense noon sunlight. Built-in smart light sensors automatically adjust screen brightness based on ambient conditions, optimizing power consumption and extending LED backlight lifespan.
IP65 All-Weather Durability & Smart Temperature ManagementHoused in a heavy-duty, anti-corrosion galvanized steel enclosure with IP65 ingress protection, this totem withstands rain, dust, and extreme weather. The integrated intelligent thermal cooling system (air fans or industrial air conditioning) guarantees 24/7 continuous, stable operation in temperature ranges from -20°C to +50°C.
Independent / Synchronized Multi-Screen Cloud CMSPowered by robust Android or Windows system architecture, each screen can be controlled independently or synchronized into a unified display strategy. Remotely update schedules, split-screen layouts, and monitor device health in real time from anywhere via cloud CMS over Wi-Fi, 4G/5G, or LAN.
Screen Sizes Available: 43", 49", 55", 65", 75", 85" (Triple-Screen Configuration)
Panel Type: Commercial Grade A+ TFT-LCD Panel (24/7 Rating)
Resolution: 1920 × 1080 Full HD / 3840 × 2160 4K UHD Per Screen
Brightness: 2500 – 4500 nits (Ultra High Brightness, Sunlight Readable under Direct Sun)
Optical Lamination: Full Optical Lamination (Zero Air Gap, Zero Internal Fogging)
Glass Specification: 4mm / 6mm AR (Anti-Reflective) & AG (Anti-Glare) Tempered Glass
Light Transmittance: ≥ 92%
Contrast Ratio: 3000:1 / 4000:1
Viewing Angle: 178° Horizontal / 178° Vertical
Brightness Control: Intelligent Auto-Dimming Light Sensor (Energy Saving & Heat Reduction)
Panel Backlight Lifespan: ≥ 50,000 Hours
Enclosure & Environmental Protection
Ingress Protection Rating: IP65 Waterproof, Dustproof, and Weatherproof
Cabinet Material: Heavy-Duty Galvanized Steel + Anti-Corrosion Outdoor Powder Coating
Thermal Management: Intelligent Temperature Control System (Smart Air Cooling Fans / Industrial Air Conditioner Optional)
Operating Temperature: -20°C to +50°C (-4°F to 122°F)
Operating Humidity: 10% – 90% RH (Non-Condensing)
Vandal Resistance: High Impact Anti-Vandal Glass & Enclosure Structure
System & Hardware Configurations (Optional)
Android OS Option: Android 11.0 / 12.0 (CPU: RK3568 / RK3588, RAM: 2GB/4GB, Storage: 16GB/32GB/64GB)
Windows OS Option: Windows 10 / 11 Pro (CPU: Intel Core i3 / i5 / i7, RAM: 8GB/16GB, Storage: 128GB/256GB SSD)
Standalone Option: Plug-and-Play USB Auto Playback
Multi-Screen Control: Independent Multi-Display Driver / Synchronized Cloud CMS
Network Connectivity: Wi-Fi / RJ45 Ethernet / 4G LTE Module (Optional)
Power & Electrical Specifications
Power Supply: AC 100V – 240V, 50/60Hz
Standby Consumption: ≤ 5W
Electrical Protection: Built-in Surge Protection & Leakage Protection Switch
Customization & Value-Added Options
Interactive Touch: Optional 10-Point PCAP Capacitive Touch Screen (Single Screen / Multi-Screen)
Custom Services: Custom Shell Colors (RAL Palette), Silk-Screen Brand Logo, Camera, Motion Sensor, IC/RFID Card Reader
Smart Transit Hubs & Airports (Railway, Bus & Flight Terminals)Maximize information flow and revenue by dedicating three screens simultaneously to real-time arrival/departure timetables, interactive route wayfinding, and high-CPM commercial sponsor advertisements—providing passengers with complete transit clarity without screen switching.
Commercial Shopping Districts & Mega PlazasCapture heavy pedestrian traffic in high-density shopping hubs. Stream dynamic 4K brand video ads on Screen 1, interactive store directories on Screen 2, and limited-time sales promotions on Screen 3. The 4500-nit ultra-high brightness guarantees vivid, eye-catching visual impact under direct, harsh sunlight.
Smart Cities & Civic Public CentersServe as multi-functional smart city totems. Allocate screen real estate to public safety broadcasts, civic event announcements, digital tourism maps, and commercial local business advertising to help offset municipal infrastructure installation costs.
Theme Parks, Stadiums & Large Event VenuesElevate visitor engagement across high-footprint venues. Display live event schedules or queue wait times on one screen, concession menus and merch deals on the second, and sponsor video commercials on the third, effectively driving on-site retail sales.
EV Charging Plazas & Highway Service StationsMonetize driver dwell time during charging sessions. The multi-display configuration allows operators to show charging status updates, convenience store promotions, and high-yield third-party advertisements on a single, durable IP65-rated totem.
| Versions=> | 1.Android WiFi Version | 2.Android WiFi Version+Nano Touch | 3.Windows WiFi | |
| System | CPU | RK3568(3399/3288/3566/3588) | RK3568(3399/3288/3566/3588) | intel i3-4th gen |
| RAM | 2GB(4/8GB) | 2GB(4/8GB) | 4GB DDR3 | |
| Internal memory | 32GB(64/128GB) | 32GB(64/128GB) | 128GB SSD | |
| Operation system | Android 11.1(8.0/10.0/12/13) | Android 11.1(8.0/10.0/12/13) | Win10pro (no license) | |
| Touch screen | w/o or nano Touch | nano Touch | w/o or nano Touch | |
| Display | Panel | IPS full view angle screen 178/178, LED backlight | ||
| Resolution | 1920*1080 FHD (optional 4K screen with extra $50/pcs) | |||
| Viewing angles | 178(H),178(V) | |||
| Contrast ratio | 3000 | |||
| Luminance | 2500cdm2(optional: 3000/3500/4000/4500nits brightness) | |||
| Aspect Ratio | ,16:9 | |||
| Network | WiFi | WiFi 802.11 | WiFi 802.11 | WiFi 802.11 |
| 3G/4G | \ | \ | \ | |
| Ethernet RJ45 | yes | yes | yes | |
| Buletooth | yes | yes | yes | |
| Interface | SD Card slot | yes | yes | no |
| USB port | yes | yes | yes | |
| WiFi port | yes | yes | yes | |
| RJ45 | yes | yes | yes | |
| on/off switch | yes | yes | yes | |
| Media play | Video format | MPEG-1,MPEG-2,MPEG-4,H.264,H.265,RV etc.,support up to 1080p | ||
| Photo | jpeg | |||
| Audio format | MP3/WMA/AAC etc. | |||
| Touch panel | optional | w/o | standard optional Nano multi touch panel (optional G+G touch add $195/pcs on base of Nano touch) | |
| Air Conditioner | w/o | |||
| Termpered glass | IK10 6mm termpered glass, high quality | |||
| Waterproof standard | IP65 Standard / IP66 Optional | |||
| Heating system | w/o, optional | |||
| AR glass | w/o, optional | |||
| Others | Power consumption | 168W | 198W | 238W |
| Speaker | 2*5W | 2*5W | 2*5W | |
| Temperature | -20 to 50degrees | -20 to 50degrees | -20 to 50degrees | |
| Language | Multi-language | Multi-language | English | |
| Adapter | Internal power board (AC100V-240V, 50/60Hz) | |||
| Accessories | AC cable, packing box, WiFi Antenna, ground base | |||
