AIYOS
Dual-Sided Synchronous Display for Double Advertising Exposure: Featuring a unique double-screen independent display design, this outdoor kiosk supports simultaneous content playback on both sides, realizing bidirectional audience coverage that single-sided screens cannot match. It maximizes advertising value in pedestrian flow-intensive road sections and public areas, effectively capturing crowds from opposite directions and doubling brand exposure efficiency, making it a high-return outdoor marketing terminal.
75-inch Large-Size 4K Ultra-Clear Visual Presentation: Adopting a super-large 75-inch 16:9 IPS full-view panel with native 4K UHD 3840×2160 ultra-high resolution and 3000:1 high contrast ratio, the device restores rich color layers and delicate picture details. The 178°×178° ultra-wide viewing angle eliminates viewing blind spots, while the 2500–4500 nits step-by-step adjustable high brightness ensures vivid, anti-glare and sunlight-readable visuals even under intense outdoor direct sunlight.
High-Level Windows Computing Performance: Different from mainstream Android outdoor screens, this kiosk is built with Intel 6th Gen i5 core processor, matched with 8GB DDR4 large memory and 128GB high-speed SSD, pre-installed with stable Windows 10 Pro system. It delivers powerful operational capacity to support complex advertising programs, dynamic interactive software and long-term uninterrupted commercial operation, with faster response speed and stronger multi-task processing capability.
Dual Heavy-Duty All-Weather Protection: Built for harsh outdoor working conditions, the whole machine adopts IP65 professional waterproof and dustproof enclosure structure, which effectively isolates rain, dust and humid air. Equipped with 6mm thick IK10 explosion-proof tempered glass, it resists external impact, scratch damage and artificial vandalism. It stably operates in the temperature range of -20°C to 50°C, with optional heating and air conditioning modules to adapt to extreme high and low temperature environments, achieving true 24/7 all-weather stable operation.
Rich Expansion & Interactive Customization: It integrates comprehensive connection interfaces including WiFi 802.11, Bluetooth, Gigabit Ethernet, HDMI-OUT, USB and VGA, supporting remote content update, multi-device linkage and signal external output. The optional capacitive nano multi-touch panel upgrades passive display to active human-computer interaction, while built-in 2×5W stereo speakers realize synchronous audio and video playback, greatly enriching outdoor publicity and interactive experience.
Brand & Custom Service: AIYOS professional outdoor commercial display brand, supports full-scene OEM / ODM personalized customization
Core Display Configuration: 75-inch large-size double-sided display, IPS full-view panel with LED backlight, 16:9 classic aspect ratio
Resolution & Visual Parameters: Native 4K UHD 3840×2160 ultra-high definition, 3000:1 high contrast ratio, 178° full viewing angle
Screen Brightness: 2500 cd/m² standard brightness, optional 3000/3500/4000/4500 nits high-brightness upgrade
Touch Function: Optional commercial-grade capacitive Nano multi-touch panel for interactive operation
Hardware Performance: Intel 6th Gen i5 processor, 8GB DDR4 RAM, 128GB SSD high-speed storage
Operating System: Windows 10 Pro (system license not included)
Protection Grade: IP65 waterproof and dustproof, 6mm IK10 impact-resistant tempered glass
Full Connectivity: WiFi 802.11, Bluetooth, Ethernet RJ45, HDMI-OUT, USB, VGA interfaces
Audio System: Built-in 2×5W stereo speakers for synchronous audio-video playback
Working Environment: Standard operating temperature: -20°C ~ 50°C; optional heating module supports -20°C ~ -40°C ultra-low temperature operation
Power Parameters: AC100-240V 50/60Hz universal internal power supply, maximum power consumption 858W
Optional Accessories: Cooling air conditioner, low-temperature heating system, anti-reflective AR glass
Installation Method: Stable freestanding floor-standing integrated structure
This 75-inch double-sided 4K outdoor kiosk is specially designed for two-way traffic outdoor public scenarios that require high-value omnidirectional advertising coverage. It is widely applied in urban road side core advertising billboards, bus stops and transit shelter information release, shopping mall entrance and square brand promotion, urban public parks and civic plazas, stadium and venue peripheral commercial publicity, airport terminal public guidance and brand display. Relying on its dual-sided simultaneous display, ultra-high-definition visual performance and high-computing stable operation, it is the preferred high-end intelligent display device for high-traffic outdoor all-weather bidirectional marketing and public information service.
| Versions=> | Windows version | |||
| System | CPU | intel i5-6th gen | ||
| RAM | 8GB DDR4 | |||
| Internal memory | 128GB SSD | |||
| Operation system | Win10pro (no license) | |||
| Touch screen | yes, optional nano Touch | |||
| Display | Panel | 75" IPS full view angle screen 178/178, LED backlight | ||
| Resolution | 4K screen with3840*2160pixels | |||
| Viewing angles | 178(H),178(V) | |||
| Contrast ratio | 3000 | |||
| Luminance | 2500cdm2(optional: 3000/3500/4000/4500nits brightness) | |||
| Aspect Ratio | ,16:9 | |||
| Network | WiFi | yes, WiFi 802.11 | ||
| 3G/4G | \ | |||
| Ethernet RJ45 | yes | |||
| Buletooth | yes | |||
| Interface | HDMI | yes, HDMI-OUT | ||
| USB port | yes | |||
| WiFi port | yes | |||
| RJ45 | yes | |||
| VGA | yes | |||
| Media play | Video format | MPEG-1,MPEG-2,MPEG-4,H.264,H.265,RV etc.,support up to 1080p | ||
| Photo | jpeg | |||
| Audio format | MP3/WMA/AAC etc. | |||
| Touch panel | yes, with capacitive Nano multi touch panel | |||
| Air Conditioner | w/o, optional | |||
| Termpered glass | IK10 6mm termpered glass, high quality | |||
| Waterproof standard | IP65 | |||
| Heating system | w/o, optional add $200/pcs for very cold condition -20 to -40 degrees | |||
| AR glass | w/o, optional | |||
| Others | Power consumption | Max 858W | ||
| Speaker | 2*5W | |||
| Temperature | -20 to 50degrees | |||
| Language | English, or other language | |||
| Adapter | Internal power board (AC100V-240V, 50/60Hz) | |||
| Accessories | AC cable, packing box, WiFi Antenna | |||
