AIYOS
Customized 29-Inch Strip Screen for Perfect Elevator Spatial Matching: Unlike conventional standard-resolution advertising screens, this machine adopts a tailor-made 29-inch long-strip FHD IPS full-view panel with 1920×720 exclusive resolution and 16:9 slender aspect ratio. The streamlined screen body design highly fits the wall installation layout of narrow elevator cabins, avoiding space crowding while maximizing vertical advertising display area. The professional strip screen ratio is more in line with people’s vertical viewing habits during short elevator rides, greatly improving advertising information reading efficiency and audience focus.
Stable Industrial-Grade Visual Performance for Indoor Elevator Lighting: Tuned for long-term stable operation in complex indoor light environments of elevator cabins, the screen features 350 cd/㎡ standard commercial brightness and 3000:1 ultra-high contrast ratio, presenting layered, high-saturation and delicate color performance. With 89° ultra-wide symmetrical viewing angles in both horizontal and vertical directions, it eliminates visual dead spots in confined cabins, ensuring passengers in all standing positions can view complete and distortion-free advertising content. The LED backlight panel delivers soft and non-glare display effects, adapting to short-distance viewing in narrow spaces for a comfortable user experience.
Four-Tier Simplified Version Matrix for Accurate Scenario Matching: Optimized for the actual operational needs of elevator advertising projects, the product launches four refined configuration versions to eliminate functional redundancy. The entry-level Mstar V56 USB version supports plug-and-play offline loop playback, meeting basic low-budget fixed advertising release; the lightweight Android WiFi version with PX30 quad-core (optional RK3288) chip and 1GB+8GB stable memory realizes convenient remote network update and real-time content scheduling; the upgraded Android capacitive touch version adds interactive functions to support novel interactive advertising modes; the top Windows version integrates dual IR/capacitive touch and thermal printer expansion, supporting customized information printing and high-intelligent interactive service scenarios.
Full-Format Audio and Video Decoding + Built-In Stereo Sound: Supporting full mainstream media formats including MPEG series, H.264, H.265, RV video decoding and MP3/WMA/AAC audio playback, the device stably outputs 1080P high-definition video resources without compression or blurriness. Matched with built-in 2×2W stereo speakers, it realizes synchronous audio and video playback, breaking the single picture display limitation of traditional elevator screens. The immersive audio-visual integration effect effectively enhances advertising appeal and information dissemination effectiveness.
Low-Power Stable Operation & Flexible Network Management: Adopting 12V 5A standard power adapter power supply, the whole machine only has 48W low power consumption, realizing energy-saving and environmental protection long-term uninterrupted operation, greatly reducing daily power operation cost. According to different versions, it is equipped with WiFi 802.11, Bluetooth and wired Ethernet RJ45 full-channel connections, plus USB and SD card local playback interfaces. It supports diverse management methods such as remote batch release, wireless real-time update and offline resource replacement, reducing property operation and maintenance difficulty.
Brand & Custom Service: AIYOS professional building elevator display solution provider, supports full-scene OEM / ODM personalized customization
Display Panel: 29-inch industrial LCD FHD IPS full-view panel, 16:9 slender commercial aspect ratio, LED backlight
Native Resolution: 1920×720 exclusive strip-screen high definition
Display Parameters: 350 cd/㎡ standard indoor brightness, 3000:1 high contrast ratio
Viewing Angle: 89° (Horizontal) / 89° (Vertical) ultra-wide viewing angle
Complete Version Classification: USB basic playback (Mstar V56); Android WiFi (PX30 quad-core / optional RK3288, 1GB+8GB, Android 8.1); Android WiFi + Capacitive Touch; Windows WiFi + Dual Touch + Thermal Printer Support
Network & Interface Configuration: WiFi 802.11, Bluetooth, Ethernet RJ45 (version-dependent), USB ports, SD card slot
Audio System: Built-in 2×2W high-fidelity stereo speakers
Media Decoding: Video: MPEG-1/2/4, H.264, H.265, RV (max 1080P); Audio: MP3, WMA, AAC
Power Parameter: 12V 5A power adapter, 48W low power consumption
Installation Method: Ultra-slim wall-mounted installation, specially designed for elevator cabin interior
This 29-inch customized strip single-screen elevator digital signage is tailored for all kinds of indoor vertical transportation cabin display scenarios. It is widely used for commercial advertising and enterprise culture promotion in office building elevators, brand image display and service notice release in hotel elevator cabins, community property announcement and commercial promotion in high-rise residential elevators, shopping mall passenger elevator marketing display, and hospital elevator public information guidance and business publicity. With low energy consumption, high definition, multi-functional scalability and simple installation, it provides efficient, stable and cost-effective targeted advertising solutions for capturing short-term captive elevator passenger flow.
