AIYOS
True IPS Full-View Visual Experience for Commercial Scenes Engineered for indoor commercial display standards, this wall-mounted screen adopts professional 16:9 IPS LCD panel with LED backlight, featuring 1920×1080 FHD resolution and a 3000:1 high contrast ratio that delivers deeper black levels and brighter highlights. With 178° horizontal and vertical ultra-wide viewing angles, the screen maintains accurate color and consistent clarity without distortion or color shift, even when viewed from side angles. Tuned to 350cd/㎡ standard indoor brightness, it perfectly adapts to conventional commercial lighting, delivering crisp, vibrant visuals ideal for retail windows, lobbies and public display areas.
Five-Tier Version Matrix for Fully Scalable Deployment What differentiates this wall signage from ordinary single-function screens is its comprehensive version lineup, covering all entry-level to high-end indoor display demands. The basic USB version supports plug-and-play offline playback with no system required, suitable for simple looping advertising. Multiple Android WiFi editions offer flexible chip options including RK3568, RK3566, RK3288, RK3399 and RK3588, paired with optional infrared and capacitive touch functions for smooth human-computer interaction. The mature Windows version provides stronger computing performance, supporting complex software operation and multi-task interactive scenarios, allowing precise configuration matching for different project budgets and functional requirements.
Iterative Hardware Configuration & Expandable Memory Supporting diversified RAM and storage combinations ranging from 2GB+16GB to 8GB+128GB, this digital signage freely upgrades operating fluency and offline resource storage capacity. Whether for simple picture and video playback or large-volume program caching and long-term continuous operation, it maintains stable and lag-free performance. Multiple mainstream core chips ensure strong equipment compatibility and long-term product iteration capability, avoiding obsolete hardware performance in short-term commercial use.
Full-Coverage Connectivity & Efficient Content Management Equipped with complete wireless and wired connection modules including WiFi, Bluetooth, Gigabit Ethernet RJ45, multi-channel USB ports and SD card slots, with optional HDMI-IN/OUT signal transceiving according to versions. It supports remote online content update, real-time program scheduling and offline local resource playback, realizing efficient and low-cost daily operation management. Built-in 2×5W high-definition stereo speakers achieve synchronized audio and video output, enriching advertising dissemination and public broadcasting effects.
Lightweight Wall-Mounted Design & Graded Power Consumption Adopting a slim wall-mounted structural design, the signage is easy to install and fits seamlessly into various indoor wall environments without occupying space. Different versions feature graded power consumption from 42W to 118W, achieving reasonable energy-saving control under different load conditions. It supports long-term unattended commercial operation, with high stability and low later maintenance cost, suitable for large-scale batch deployment in commercial buildings and chain stores.
Brand & Custom Service: AIYOS professional indoor commercial display brand, supports full-scene OEM / ODM customized development
Display Panel: Industrial LCD IPS full-view panel, LED backlight, 16:9 commercial standard aspect ratio
Resolution: FHD 1920×1080 high definition
Brightness & Contrast: 350 cd/m² standard indoor brightness, 3000:1 high contrast ratio
Viewing Angle: 178° (H) / 178° (V) ultra-wide full viewing angle
Full Version Classification: USB standalone version (Allwinner F133, no OS); Android WiFi multi-chip version; Android WiFi + IR touch; Android WiFi + Capacitive touch; Windows WiFi + dual touch optional version
Android Configuration: Optional RK3568/RK3566/RK3288/RK3399/RK3588 processors, standard 2GB RAM + 16GB storage, Android 11.0 system
Windows Configuration: Intel i3-3110M processor, 4GB DDR3, 64GB SSD, Win10 system
Memory & Storage Expansion: Optional 2GB/4GB/8GB RAM + 16GB/32GB/64GB/128GB storage (version dependent)
Connectivity Interfaces: WiFi 802.11, Bluetooth, Ethernet RJ45, USB ports, SD card slot, HDMI-IN/OUT (configurable by version)
Audio System: Built-in 2×5W stereo speakers for synchronous audio-video playback
Power Consumption: 42W–118W, dynamically adjusted according to different configuration versions
Installation Method: Standard wall-mounted fixed installation, simple and space-saving
This multi-version wall-mounted FHD IPS digital signage is tailored for diverse lightweight indoor commercial display and information interaction scenarios. It is widely applied in retail store window brand promotion and product display, enterprise office lobby image publicity and guide display, hotel front desk reception information release, shopping mall indoor advertising and activity notification, restaurant electronic menu board updating, conference room intelligent presentation equipment, exhibition hall display and exhibition guidance, as well as public information broadcasting in transportation hubs. With flexible configuration options from basic static playback to high-frequency interactive operation, it is a cost-effective and highly adaptable wall-mounted display solution for all kinds of indoor commercial environments.
