AIYOS
Dual-Sided Synchronous Display to Maximize Indoor Traffic Coverage: Different from traditional single-sided indoor signage with limited viewing range, this freestanding kiosk adopts an innovative dual-screen symmetrical design. Both sides are equipped with independent high-quality IPS display panels, enabling simultaneous advertising playback and information display. It can capture pedestrian traffic from two opposite directions in shopping mall corridors, lobby centers and passage spaces, effectively solving the blind spot problem of single-sided screens and greatly improving commercial communication efficiency and brand exposure rate.
Rich Size & Tiered Configuration for Full-Scenario Adaptation: The product covers 32-inch, 43-inch, 49-inch, 55-inch and 65-inch multi-size specifications, among which 55-inch and 65-inch large-size models support optional 4K UHD ultra-high-definition upgrade, matching different space sizes and display precision requirements. It features five differentiated configuration versions, ranging from basic USB offline playback, Android WiFi non-touch version, Android infrared/capacitive touch interactive version to Intel i3 Windows high-performance version, allowing customers to select targeted solutions according to budget and functional needs.
Balanced High-Quality Visual Performance for Indoor Commercial Use: Adopting professional 16:9 industrial IPS full-view panels with LED backlight, the kiosk delivers standard 1920×1080 FHD resolution, 3000:1 high contrast ratio and 89°×89° stable viewing angle. The 350 cd/m² fine-tuned indoor high brightness precisely adapts to conventional indoor lighting environments, avoiding excessive glare or dim picture problems. It presents layered, delicate and color-accurate display effects, suitable for long-term indoor brand display and public information release.
Complete Connectivity & Efficient Content Operation: Matched with comprehensive and differentiated connection modules according to different versions, it supports WiFi wireless networking, Ethernet wired stable transmission, Bluetooth linkage, USB local playback and SD card resource expansion. It realizes one-stop functions including remote content update, real-time program switching and offline cyclic playback, with simple operation and low later maintenance threshold. Equipped with 2×3W or 2×5W high-definition stereo speakers, it achieves coordinated audio and video output to enrich interactive and promotional atmosphere.
Freestanding Integrated Design & High Customization: The all-in-one floor-standing structure requires no complicated wall-mounted installation and auxiliary brackets, enabling flexible placement and mobile adjustment at any time. It perfectly fits temporary exhibitions, mobile promotions and fixed lobby display scenarios. Supported by AIYOS mature OEM/ODM customized services, it can adjust hardware configurations, touch functions and appearance details to meet personalized commercial project requirements.
Brand & Custom Service: AIYOS indoor commercial display specialist, supports full-range OEM / ODM personalized customization
Optional Screen Sizes: 32”, 43”, 49”, 55”, 65” multi-size optional, 55”/65” support 4K UHD resolution upgrade
Display Resolution: Standard FHD 1920×1080, optional 4K UHD ultra-high definition (large-size models)
Panel Specification: Industrial LCD IPS full-view panel, 16:9 commercial standard aspect ratio, LED backlight
Screen Brightness: 350 cd/m² indoor professional brightness, optimized for indoor ambient light
Contrast Ratio: 3000:1 high contrast, outstanding picture layering and detail performance
Viewing Angle: 89° horizontal and 89° vertical stable viewing angle
Configuration Versions: Multiple optional versions including basic USB playback, Android WiFi non-touch, Android IR/capacitive touch, Windows Intel i3 high-performance version
Connectivity: WiFi 802.11, Bluetooth, Ethernet RJ45, USB ports, SD card slot (configurations vary by version)
Audio System: Built-in 2×3W / 2×5W stereo speakers (model-dependent configuration)
Installation Method: Integrated floor-standing / freestanding placement, flexible and convenient deployment
This multi-configurable double-sided indoor floor-standing kiosk is designed for high-exposure indoor commercial and public service scenarios. It is widely used for advertising display and guidance in shopping mall atriums, corridors and key passages, retail store window dual-sided publicity, hotel lobby brand image display and information inquiry, exhibition and trade show interactive booth display, enterprise front desk reception demonstration, museum and art gallery intelligent guide terminals, as well as airport and transportation hub public information release. It is a cost-effective and highly flexible dual-screen display solution integrating fixed publicity, mobile deployment and human-computer interaction.
| 32", ID: ADV3231(double-side) | 43", ID: ADV4331(double-side) | 49", ID: ADV5031(double-side) | 55", ID: ADV5531(double-side) | 65", ID: ADV6531(double-side) | ||||||||||||||||||||
| Versions: | 1.USB version | 2.Android WiFi Version | 4.Android WiFi+ Capacitive Touch | 5.Windows WiFi+ IR/Capacitive Touch | 1.USB version | 2.Android WiFi Version | 3.Android WiFi+ IR Touch | 4.Android WiFi+ Capacitive Touch | 5.Windows WiFi+ IR/Capacitive Touch | 1.USB version | 2.Android WiFi Version | 3.Android WiFi+ IR Touch | 4.Android WiFi+ Capacitive Touch | 5.Windows WiFi+ IR/Capacitive Touch | 1.USB version | 2.Android WiFi Version | 3.Android WiFi+ IR Touch | 4.Android WiFi+ Capacitive Touch | 5.Windows WiFi+ IR/Capacitive Touch | 1.USB version | 2.Android WiFi Version | 3.Android WiFi+ IR Touch | 4.Android WiFi+ Capacitive Touch | 5.Windows WiFi+ IR/Capacitive Touch |
| CPU | F133 | RK3288 | RK3288 | i3-3rd gen | Mstar V56 | RK3288 | RK3288 | RK3288 | i3-3rd gen | Mstar V56 | RK3288 | RK3288 | RK3288 | i3-3rd gen | Mstar V56 | RK3288 | RK3288 | RK3288 | i3-3rd gen | Mstar V56 | RK3288 | RK3288 | RK3288 | i3-3rd gen |
| RAM | w/o | 2GB | 2GB | 4GB DDR3 | w/o | 2GB | 2GB | 2GB | 4GB DDR3 | w/o | 2GB | 2GB | 2GB | 4GB DDR3 | w/o | 2GB | 2GB | 2GB | 4GB DDR3 | w/o | 2GB | 2GB | 4GB DDR3 | |
| Internal memory | w/o | 16GB | 16GB | 64GB SSD | 8GB | 16GB | 16GB | 16GB | 64GB SSD | 8GB | 16GB | 16GB | 16GB | 64GB SSD | 8GB | 16GB | 16GB | 16GB | 64GB SSD | 8GB | 16GB | 16GB | 16GB | 64GB SSD |
| Operation system | w/o | Android 7.1 | Android 7.1 | Win10(not activated) | w/o | Android 7.1 | Android 7.1 | Android 7.1 | Win10(not activated) | w/o | Android 7.1 | Android 7.1 | Android 7.1 | Win10(not activated) | w/o | Android 7.1 | Android 7.1 | Android 7.1 | Win10(not activated) | w/o | Android 7.1 | Android 7.1 | Android 7.1 | Win10(not activated) |
| Touch screen | w/o | w/o | Capacitive Touch | w/o or IR or capacitive | w/o | w/o | IR Touch | Capacitive Touch | w/o or IR or capacitive | w/o | w/o | IR Touch | Capacitive Touch | w/o or IR or capacitive | w/o | w/o | IR Touch | Capacitive Touch | w/o or IR or capacitive | w/o | w/o | IR Touch | Capacitive Touch | w/o or IR or capacitive |
| Display screen: | 32" LCD FHD IPS full view angle screen, 1920*1080 FHD, LED backlight | 43" LCD FHD IPS full view angle screen, 1920*1080 FHD, LED backlight | 49" LCD FHD IPS full view angle screen, 1920*1080 FHD, LED backlight | 55" LCD FHD IPS full view angle screen, 1920*1080 FHD(or 4K UHD), LED backlight | 65" LCD FHD IPS full view angle screen, 1920*1080 FHD(or 4K UHD), LED backlight | |||||||||||||||||||
| View angle: 89/89(H),89/89(V); Contrast ratio:3000; Brightness: 350cdm2; Ratio: 16:9 | View angle: 89/89(H),89/89(V); Contrast ratio:3000; Brightness: 350cdm2; Ratio: 16:9 | View angle: 89/89(H),89/89(V); Contrast ratio:3000; Brightness: 350cdm2; Ratio: 16:9 | View angle: 89/89(H),89/89(V); Contrast ratio:3000; Brightness: 350cdm2; Ratio: 16:9 | View angle: 89/89(H),89/89(V); Contrast ratio:3000; Brightness: 350cdm2; Ratio: 16:9 | ||||||||||||||||||||
| WiFi | w/o | WiFi 802.11 | WiFi 802.11 | WiFi 802.11 | w/o | WiFi 802.11 | WiFi 802.11 | WiFi 802.11 | WiFi 802.11 | w/o | WiFi 802.11 | WiFi 802.11 | WiFi 802.11 | WiFi 802.11 | w/o | WiFi 802.11 | WiFi 802.11 | WiFi 802.11 | WiFi 802.11 | w/o | WiFi 802.11 | WiFi 802.11 | WiFi 802.11 | WiFi 802.11 |
| 3G/4G | w/o | optional | optional | optional | w/o | optional | optional | optional | optional | w/o | optional | optional | optional | optional | w/o | optional | optional | optional | optional | w/o | optional | optional | optional | optional |
| Ethernet RJ45 | w/o | yes | yes | yes | w/o | yes | yes | yes | yes | w/o | yes | yes | yes | yes | w/o | yes | yes | yes | yes | w/o | yes | yes | yes | yes |
| Buletooth | w/o | yes | yes | yes | w/o | yes | yes | yes | yes | w/o | yes | yes | yes | yes | w/o | yes | yes | yes | yes | w/o | yes | yes | yes | yes |
| SD Card slot | yes | yes | no | w/o | yes | yes | yes | no | w/o | yes | yes | yes | no | w/o | yes | yes | yes | no | w/o | yes | yes | yes | no | w/o |
| USB port | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes |
| WiFi port | w/o | yes | yes | yes | w/o | yes | yes | yes | yes | w/o | yes | yes | yes | yes | w/o | yes | yes | yes | yes | w/o | yes | yes | yes | yes |
| RJ45 | w/o | yes | yes | yes | w/o | yes | yes | yes | yes | w/o | yes | yes | yes | yes | w/o | yes | yes | yes | yes | w/o | yes | yes | yes | yes |
| on/off switch | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes | yes |
| Video format | MPEG-1,MPEG-2,MPEG-4,H.264,H.265,RV etc.,support up to 1080p | MPEG-1,MPEG-2,MPEG-4,H.264,H.265,RV etc.,support up to 1080p | MPEG-1,MPEG-2,MPEG-4,H.264,H.265,RV etc.,support up to 1080p | MPEG-1,MPEG-2,MPEG-4,H.264,H.265,RV etc.,support up to 1080p | MPEG-1,MPEG-2,MPEG-4,H.264,H.265,RV etc.,support up to 1080p | |||||||||||||||||||
| Audio format | MP3/WMA/AAC etc. | MP3/WMA/AAC etc. | MP3/WMA/AAC etc. | MP3/WMA/AAC etc. | MP3/WMA/AAC etc. | |||||||||||||||||||
| Photo | jpeg | jpeg | jpeg | jpeg | jpeg | |||||||||||||||||||
| Power consumption | 48W | 60W | 60W | 78W | 60W | 78W | 78W | 78W | 118W | 72W | 118W | 118W | 118W | 188W | 72W | 118W | 118W | 118W | 188W | 72W | 118W | 118W | 118W | 188W |
| Speaker | 2*3W | 2*3W | 2*3W | 2*5W | 2*5W | 2*5W | 2*5W | 2*5W | 2*5W | 2*5W | 2*5W | 2*5W | 2*5W | 2*5W | 2*5W | 2*5W | 2*5W | 2*5W | 2*5W | 2*5W | 2*5W | 2*5W | 2*5W | 2*5W |
| Front Camera | w/o | w/o | w/o | w/o | w/o | w/o | w/o | w/o | w/o | w/o | w/o | w/o | w/o | w/o | w/o | w/o | w/o | w/o | w/o | w/o | w/o | w/o | w/o | w/o |
| Language | Multi-language | Multi-language | Multi-language | English | Multi-language | Multi-language | Multi-language | Multi-language | English | Multi-language | Multi-language | Multi-language | Multi-language | English | Multi-language | Multi-language | Multi-language | Multi-language | English | Multi-language | Multi-language | Multi-language | Multi-language | English |
| Adapter | Internal power board (AC100-240V) | Internal power board (AC100-240V) | Internal power board (AC100-240V) | Internal power board (AC100-240V) | Internal power board (AC100-240V) | |||||||||||||||||||
